Model

BJ1030EVJA72

Resource category

EWF4-2.5T-CATL（41.86kwh）

Product platform

EW4

Cab

Double row 1650 load-supporting

Driving Type

4×2

Cab-by the number

5

Steering wheel position

LHD

GVW

3030kg

Curb weight-chassis

1320 kg

Load Mass

1710 kg

Curb weight-Deck

1465kg

Payload/Number of Person-Deck

1195kg

Curb weight-Box

1635kg

Payload/Number of Person-Box

1065kg

Dimension（Chassis）

4620×1710×1910

Dimension（Deck）

4865×1710×1990

Dimension（BOX）

4930×1710×2520

Cargo Dimension

2140×1570×360
2020×1570×1700

Loading height

787mm

Wheel base

3080mm

Maximum Speed

90 km/h

Grade Ability

20%

Turning Radius

5.5m

Range- WLTP

180 km

AC Charge / DC charge

（SOC 20% -100%)

6 h / 1.1 h

Motor Type

permanent magnet synchronous motor

Power Rate/Peak

35/75 kw

Torque Rate/Peak

105/220 Nm

Rear axle type

Electric drive bridge

（PEU/CDU）Type

4 in 1

Integration unit

OBC  / DCDC / PDU / MCU

Voltage（VDC）

335V

Max. current

300Aac

Battery Composition Material

LFP

Traction Battery Capacity

41.86Kw.h

Traction Battery Voltage

334.88V

Traction Battery Weight

299±9kg

Traction Battery Cooling type

Natural cooling

Traction Battery Layout

Middle of the longitudial beam

Charge mode

AC/DC

OBC Charge

6.6 kw

BMS Max. allowed charging power (kW)

40kw

Charging socket

GB

Front suspension

macpherson independent suspension

Front stabilizer bar

●

Rear suspension

leaf spring

Pieces of leaf spring

5

Rear stabilizer bar

○

Steering type

Pinion-and-rack

Steering Power form

Electric power steering

multi-function steering wheel

●

tyre（standard）

175/75R14 10PR

Number of tires

4+1

Tubeless

●

Rim（steel）

●

Rim（aluminum）

×

Brake

Hydraulic brake

Front brake

disc

Rear brake

drum

Parking brake

EPB

Palt voltage

12 V

Battery capacity * Quantity

36A·h
